10. OPTIONS
10.1. CENTRAL STEAM UNIT (FABRIC FITTED)
For NC 430D / NC 570D / NC 710D double door steam sterilizer, If central steam unit is selected,
steam feed should be provided by installing a steam line from an external steam supply at the
area where the autoclave is installed in and internal steam generator which is on the device
should be deactivated
10.2. CENTRAL STEAM UNIT OPTION
For NC 430D / NC 570D / NC 710D double door steam sterilizer, when steam supply is requested
from an external steam generator, make the followings changes:
Connect the device and the steam line which is came from the external steam generator.
Choose “Steam Generator-Central” option by following Settings>>Maintenance pages.
Figure 13 – Maintenance Page
Valve position should be changed according to the steam supply which is selected from the
screen.
o If the internal steam generator which is placed on the device is used, select the
“STEAM GENERATOR-Internal” option from the screen and turn “Internal-Device”
valve to ON position, turn “Central-Customer” valve to OFF position.
o If the external steam generator is used, select the “STEAM GENERATOR-Central”
option from the screen and turn “ Internal-Device” valve to OFF position, “Central-
Customer” valve to ON position.
