Bottom View Interface
J2
External RTC Battery wafer
J3
Input Power – 4.2mm Pitch 90° ATX Power 4P
J4
OD 5.5/2.5 DC Jack with Lock
J6
HDMI Type-A Vertical Side Connector with lock (Female)
J7
M.2 E-Key Socket
J8
M.2 M-Key Socket
J10
FPC connector for 4-lane MIPI CSI-2
J11
FPC connector for 4-lane MIPI CSI-2
J13
USB 3.2 Gen2 Dual Port Type A Connector
J14
USB 3.2 Gen2 Type A Connector
J15
Gigabit Ethernet Connector w/LEDs
J16
Gigabit Ethernet Connector w/LEDs (PSE Option)
J17
USB type C
J18
20-pin Expansion Terminal Block
SW2
DIP switch
SW3
Power Button w/LEDs
SW4
Recovery Button w/LEDs
JP2
WDT function setting
J27
Power button wafer
J24
PSE Board Connector (Maximum 15W)
