NVIDIA DGX H100 User Guide
Table 1: Table 8. BMC Main Controls
Control Description
Quick Links Provides quick access to several tasks.
Dashboard Displays the overall information about the status
of the device.
Sensor Provides status and readings for system sensors,
such as SSD, PSUs, voltages, CPU temperatures,
DIMM temperatures, and fan speeds.
System Inventory Displays inventory information of system mod-
ules.
FRU Information System, Processor, Memory Controller, Base-
Board, Power, Thermal, PCIE Device, PCIE Func-
tion, and Storage.
GPU Information Provides basic information on all the GPUs in
the systems, including GUID, VBIOS version, In-
foROM version, and number of retired pages for
each GPU.
Logs and Reports View, and if applicable, download and erase, the
IPMI event log, and System, Audit, Video, and
POST Code logs.
Settings Congure the following settings:
Captured BSOD, External User Services, KVM
Mouse Setting, Log Settings, Media Redirection
Settings, Network Settings, PAM Order Settings,
Platform Event Filter, Services, SMTP Settings,
SSL Settings, System Firewall, User Manage-
ment, and Video Recording
Remote Control Opens the KVM Launch page to remotely access
the DGX H100 console.
Power Control Perform the following power actions:
Power On, Power O, Power Cycle, Hard Reset,
and ACP/Shutdown
Chassis ID LED Control “Virtual LED” is a button to toggle the UID LED
on/o:
▶ O
▶ Solid on
▶ Blinking on (select from ve (5) to 255 sec-
ond blink interval). This is activated by
the “Chassis Identify LED” option above the
“Quick Links” drop down.
Maintenance Perform the following maintenance tasks:
Backup Conguration, Firmware Image Location,
Firmware Update, Preserve Conguration, Re-
store Conguration, Restore Factory Defaults,
and System Administrator
Sign out Sign out of the BMC web UI.
42 Chapter 6. Using the Baseboard Management Controller (BMC)

Nvidia DGX H100 Specifications

General

GPU	8x NVIDIA H100 Tensor Core GPUs
GPU Memory	640 GB HBM3 (80GB per GPU)
System Memory	2 TB DDR5
Form Factor	6U rackmount
Storage	30TB NVMe SSD
Power Supply	10kW
Interconnect	NVLink 4.0
