Chapter 1. Introduction to the NVIDIA

DGX H100 System

The NVIDIA DGX H100 System is the universal system purpose-built for all AI infrastructure and work-

loads, from analytics to training to inference. The system is built on eight NVIDIA H100 Tensor Core

GPUs.
