Chapter 11. Audio
NVIDIA Orin supports multiple PCM and I2S audio interfaces. It also includes a flexible audio
port switching architecture.
Table 11-1. Orin Module Audio Pin Descriptions
Pin #
Module Pin
Name
Orin Signal
Usage/Description
Recommended
Usage
Direction
Pin Type
199
I2S0_SCLK
GP122
I2S Audio Port 0 Clock
Audio Device
Bidir
CMOS
1.8V
197
I2S0_FS
GP125
I2S Audio Port 0 Left/Right Clock
Bidir
193
I2S0_DOUT
GP123
I2S Audio Port 0 Data Out
Output (note)
195
I2S0_DIN
GP124
I2S Audio Port 0 Data In
Input (note)
226
I2S1_SCLK
GP206_DAP4_CLK
I2S Audio Port 1 Clock
Audio Device (i.e.
M.2 Key E)
Bidir
224
I2S1_FS
GP209_DAP4_FS
I2S Audio Port 1 Left/Right Clock
Bidir
220
I2S1_DOUT
GP207_DAP4_DOUT
I2S Audio Port 1 Data Out
Output (note)
222
I2S1_DIN
GP208_DAP4_DIN
I2S Audio Port 1 Data In
Input (note)
211
GPIO09
GP167
GPIO #9 or Audio Codec Initiator Clock
Audio Device
Output (note)
Notes:
1. In the Direction column, Output is from Orin module. Input is to Orin module. Bidir is for Bidirectional signals.
2. The direction indicated for I2S[1:0]_DOUT and _DIN are associated with their use as I2S data lines. The direction for GPIO09 is associated with its use
as Audio Initiator Clock. The pins support GPIO functionality, so support both input and output operation (bidirectional).
