28
3-7 Integrated Peripherals
CMOS Setup Utility-Copyright(c) 1985-2005 America Megatrends, Inc
Integrated Peripherals
Item Help
Onboard IDE function Press Enter
Onboard Device Press Enter
Super IO Configuration Press Enter
Menu Level >
↑↓<->: Move Enter: Select +/-/: Value F10: Save ESC: Exit F1: General Help
F7: Previous values F8: Fail-safe Defaults F9: Optimized Defaults
3-7-1 Super IO Configuration
CMOS Setup Utility-Copyright(c) 1985-2005 America Megatrends, Inc
Super IO Configuration
Item Help
Configure FT1862 Super IO Chipset
Onboard Floppy Controller Enabled
Serial Port 1 Address 3F8/IRQ4
Parallel Port Address Disabled
AC Loss Auto Restart Always-off
Menu Level >>
↑↓<->: Move Enter: Select +/-/: Value F10: Save ESC: Exit
F1: General Help F7: Previous values F8: Fail-safe Defaults
F9: Optimized Defaults
Onboard Floppy Controller
Allows BIOS to Enable or Disable Floppy Controller.
3-7-2 Onboard IDE Device
CMOS Setup Utility-Copyright(c) 1985-2005 America Megatrends, Inc
Onboard IDE Function
Item Help
RAID Setup Press Enter
Onboard IDE Controller Enabled
Serial-ATA Devices Device 011
Hard Disk Write Protect Disabled
IDE Detect Time out (sec) 35
ATA (PI) 80 pin Cable Detect Host&Device
Menu Level >>
↑↓<->: Move Enter: Select +/-/: Value F10: Save ESC: Exit F1: General Help
F7: Previous values F8: Fail-safe Defaults F9: Optimized Defaults
RAID Setup
While entering setup, you can choose Enabled or Disabled RAID mode for each ATA
channels.
Onboard IDE Controller
Disabled: Disables the integrated IDE controller. PRIMARY: enables only the primary
IDE controller. SECONDARY: enables only the secondary IDE controller. BOTH:
enables IDE controller.
