1-2 Specification
Spec Description
Design z
ATX form factor 4 layers PCB size: 29.5cm*19.5cm
Chipset z
MCP61 Chipset(for
M26GTC-E-LF,M26GTC-ED-LF,M26GTCV2-LF
，
M26GTCPV2-LF
)
z
MCP65S(for M26GTC-LF,M26GTCD-LF,M26GTCP-LF)
CPU Socket AM2
z
Support 64bit AMD AM2 940-Pin package utilizes
Flip-Chip Pin Grid Array package compatible processor
z
Support for HT 1GHz AMD Athlon 64 X2 processor
Memory Socket
z
240-pin DDR2 Module socket x 2
z
Support 2 pcs DDR2 533 / DDR2 667 / DDR2 800 Modules
Expandable to 4GB
Expansion Slot
z
PCI-Express x16 slot 1pcs deliver up to 8GB/s concurrent
bandwidth
z
32-bit PCI slot x 3pcs
z
PCI-Express x1 slot x 1pcs
Integrate IDE and
Serial ATA2 RAID
z
One IDE controllers support PCI Bus Mastering, ATA
PIO/DMA and the ULTRA DMA 33/66/100/133 functions
that deliver the data transfer rate up to 133 MB/s.
z
Serial ATA2 ports provide 300 MB/sec data transfer rate
with RAID 0,1,5(optional),0+1(optional) function.
LAN
z
Integrated Gigabit PCI-E LAN.
z
Supports Fast Ethernet LAN function provide
10/100/1000Mb /s data transfer rate
z
Integrated Megabit PCI-E LAN.(only for M26GTCP-LF
，
M26GTCPV2-LF
)
z
Supports Fast Ethernet LAN function provide 10/100Mb /s
data transfer rate.(only for M26GTCP-LF
，
M26GTCPV2-LF
)
6-CH Audio z
6-channel High Definition Audio CODEC on board
z
Support 6-channel 3D surround & Positioning Audio
z
Audio driver and utility included
BIOS z
AMI 8MB SPI Flash ROM
Multi I/O z
PS/2 keyboard and PS/2 mouse connectors
z
Floppy disk drive connector x1
z
Parallel port x1
z
Serial port x1
z
Serial ATA connector x2(for
M26GTC-E-LF,M26GTC-ED-LF,M26GTCV2-LF
，
M26GTCPV2-LF
)
z
Serial ATA connector x4(for
M26GTC-LF,M26GTCD-LF,M26GTCP-LF)
z
USB2.0 port x 4 and headers x 2 (for
M26GTC-E-LF,M26GTC-ED-LF,M26GTCV2-LF
，
M26GTCPV2-LF
)
z
USB2.0 port x 4 and headers x 3(for
M26GTC-LF,M26GTCD-LF,M26GTCP-LF)
z
Audio connector (Line-in, Line-out, MIC/ 6CH Audio)
