3-9 Miscellaneous Control
This section is for setting CPU Frequency/Voltage Control.
CMOS Setup Utility-Copyright(c) 1985-2005 America Megatrends, Inc
Miscellaneous Control
Item Help
Advanced PCI/PnP Settings
CPU/LDT Spread Spectrum Disabled
PCIE Spread Spectrum Disabled
SATA Spread Spectrum Disabled
IRQ Resources Press Enter
Palette Snooping Disabled
Menu Level >
↑↓<->: Move Enter: Select +/-/: Value F10: Save ESC: Exit
F1: General Help F7: Previous values F8: Fail-safe Defaults
F9: Optimized Defaults
CPU/LDT/PCIE/SATA Spread Spectrum
This item allows you to set the CPU Host / SATA /PCIE clock and Spread Spectrum.
The settings are: Enabled, Disabled.
IRQ Resources
When resources are controlled manually, assign each system interrupt a type,
depending on the type of device using the interrupt. There are seven items to select,
IRQ5, IRQ7, IRQ9, IRQ10, IRQ11, IRQ14, and IRQ15.
Palette Snoop
Enabled: informs the PCI devices that an ISA graphics device is installed in the
system so the card will function correctly.
3-10 PC Health Status
This section shows the Status of you CPU, Fan, Warning for overall system status.
This is only available if there is Hardware Monitor onboard.
CMOS Setup Utility-Copyright(c) 1985-2005 America Megatrends, Inc
PC Health Status
Item Help
PC Health Status
SMART FAN Configuration Press Enter
H/W Health Function Enabled
CPU Temperature 48/118
SYS Temperature 36/98
FAN1 Speed 2732RPM
FAN2 Speed N/A
FAN3 Speed N/A
Vcore 1.369V
NB 1.241V
+5V 5.279V
+12V 12.448V
5VSB 5.323V
VDIMM 1.904V
VBAT 3.104V
Menu Level >
↑↓<->: Move Enter: Select +/-/: Value F10: Save ESC: Exit
F1: General Help F7: Previous values F8: Fail-safe Defaults
F9: Optimized Defaults
