Nvidia Mellanox ConnectX-6 MCX654106A-ECAT - MCX653106 A-HDAT Specifications

71
Voltage: 3.3Aux
Maximum current:100mA
Maximum power available through QSFP56 port: 5W
Envi
ron
men
tal
Temperature Operational 0°C to 55°C
Non-operational -40°C to 70°C
Humidity: 90% relative humidity
c
Airflow (LFM) /
Ambient
Temperature
Cable Type
Airflow Direction
Heatsink to Port Port to Heatsink
Passive Cables 350 LFM / 55°C 250 LFM / 35°C
Mellanox Active 4.7W Cables
500 LFM / 55°C
d
250 LFM / 35°C
Reg
ulat
ory
Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Notes: a.The ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit
error rates and longer cable reaches. This supplemental feature only initiates when connected to
another Mellanox InfiniBand product.
b.Typical power for ATIS traffic load.
c. For both operational and non-operational states.
d.For engineering samples - add 250LFM
MCX653106A-HDAT Specifications
Physical Adapter Card Size: 6.6 in. x 2.71 in. (167.65mm x 68.90mm)
Connector: Dual QSFP56 InfiniBand and Ethernet (copper and optical)
Protocol
Support
InfiniBand: IBTA v1.35
a
Auto-Negotiation: 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per
lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port,
HDR100 (2 lane x 50Gb/s per lane), HDR (50Gb/s per lane) port
Please make sure to install the ConnectX-6 card in a PCIe slot that is capable of supplying the
required power and airflow as stated inthe below table.

