Nvidia Mellanox ConnectX-6 MCX654106A-ECAT - MCX653106 A-ECAT Specifications

74
Mellanox Active
2.7W Cables
300 LFM / 55°C 200 LFM / 35°C
Regulatory Safety: CB / cTUVus / CE
EMC: CE / FCC / VCCI / ICES / RCM / KC
RoHS: RoHS Compliant
Notes: a.The ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit
error rates and longer cable reaches. This supplemental feature only initiates when connected to
another Mellanox InfiniBand product.
b.Typical power for ATIS traffic load.
c. For both operational and non-operational states.
MCX653106A-ECAT Specifications
Physical Adapter Card Size: 6.6 in. x 2.71 in. (167.65mm x 68.90mm)
Connector: Dual QSFP56 InfiniBand and Ethernet (copper and optical)
Protocol
Support
InfiniBand: IBTA v1.3
a
Auto-Negotiation: 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per
lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port,
HDR100 (2 lane x 50Gb/s per lane) port
Ethernet: 100GBASE-CR4, 100GBASE-KR4, 100GBASE-SR4, 50GBASE-R2, 50GBASE-R4,
40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4, 40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2,
25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER, 10GBASE-CX4, 10GBASE-CR,
10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
Data Rate InfiniBand SDR/DDR/QDR/FDR/EDR
Ethernet 1/10/25/40/50/100 Gb/s
Gen3/4: SERDES @ 8.0GT/s/16GT/s, x16 lanes (2.0 and 1.1 compatible)
Adapter Card
Power
Voltage: 12V, 3.3VAUX
Power Cable
Typical Power
b
Passive Cables 21.0W
Please make sure to install the ConnectX-6 card in a PCIe slot that is capable of supplying the
required power and airflow as stated inthe below table.

For power specifications when using a single-port configuration, please refer to MCX653105A-
ECAT Specifications

