Environm
ental
Airflow
(d)
Cable
Type
Hot Aisle - HSK to Port Cold Aisle @35C - Port to
HSK
Active Mode@
55C
STBY Mode@
45C
Active
Mode
STBY Mode
Passive
Cable
500LFM 100LFM 200LFM 100LFM
Active
4.55W Cable
700LFM@50C 300LFM 200LFM 100LFM
Regulator
y
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
a.ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit error rates
and longer cable reaches. This supplemental feature only initiates when connected to another
Mellanox InfiniBand product.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
d. Airflow numbers are measured while using Mellanox HDR optic cable. The maximum allowed
temperature (internal sensor) for Mellanox HDR optic cable is 75C.
MCX653436A-HDAISpecifications
Physical
Size: 2.99 in. x 4.52 in (76.00mm x 115.00mm)
Connector: Dual QSFP56 InfiniBand and Ethernet (copper and optical)
Retention Mechanism: Internal Lock
Protocol
Support
Ethernet: 200GBASE-CR4, 200GBASE-KR4, 200GBASE-SR4, 100GBASE-CR4, 100GBASE-KR4,
100GBASE-SR4, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4,
40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,
10GBASE-ER, 10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX,
10GBASE-SR
InfiniBand: IBTA v1.3
Auto-Negotiation
(a)
: 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per
lane), FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port,
HDR100 (2 lane x 50Gb/s per lane), HDR (50Gb/s per lane) port
Data Rate: Ethernet 1/10/25/40/100/200 Gb/s
InfiniBand SDR/DDR/QDR/FDR/EDR/HDR100/HDR
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (3.0 and 1.1 compatible)
Please make sure to install the ConnectX-6 OCP 3.0 card in a PCIe slot that is capable of
supplying 80W.
