Active 3.5W Cable 700LFM 200LFM 150LFM 100LFM
Regul
atory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
a. ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit error rates
and longer cable reaches. This supplemental feature only initiates when connected to another
Mellanox InfiniBand product.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
d. Mellanox 100Gb/s Cable.
MCX653435A-HDAE Specifications
Physi
cal
Size: 2.99 in. x 4.52 in (76.00mm x 115.00mm)
Connector: Single QSFP56 InfiniBand and Ethernet (copper and optical)
Retention Mechanism: Ejector Latch
Proto
col
Suppo
rt
Ethernet: 200GBASE-CR4, 200GBASE-KR4, 200GBASE-SR4, 100GBASE-CR4, 100GBASE-KR4,
100GBASE-SR4, 50GBASE-R2, 50GBASE-R4, 40GBASE-CR4, 40GBASE-KR4, 40GBASE-SR4,
40GBASE-LR4, 40GBASE-ER4, 40GBASE-R2, 25GBASE-R, 20GBASE-KR2, 10GBASE-LR,10GBASE-ER,
10GBASE-CX4, 10GBASE-CR, 10GBASE-KR, SGMII, 1000BASE-CX, 1000BASE-KX, 10GBASE-SR
InfiniBand: IBTA v1.3
Auto-Negotiation
(a)
: 1X/2X/4X SDR (2.5Gb/s per lane), DDR (5Gb/s per lane), QDR (10Gb/s per lane),
FDR10 (10.3125Gb/s per lane), FDR (14.0625Gb/s per lane), EDR (25Gb/s per lane) port, HDR100 (2
lane x 50Gb/s per lane), HDR (50Gb/s per lane) port
Data Rate: Ethernet 1/10/25/40/100/200 Gb/s
InfiniBand SDR/DDR/QDR/FDR/EDR/HDR100/HDR
PCI Express Gen 4.0: SERDES @ 16.0GT/s, 16 lanes (3.0 and 1.1 compatible)
Powe
r
Voltage: 3.3VAUX, 12V
Power Cable Type Active Mode STBY Mode
Typical Power
(b)
Passive Cables 18.53W 6.6W
Maximum
Power
Passive Cables 23.3W 10.45W
3.5W Active
Cables
28.5W 15.6W
Maximum power available through QSFP56 port:4.55W
Temperature Operational 0°C to 55°C
Please make sure to install the ConnectX-6 OCP 3.0 card in a PCIe slot that is capable of
supplying 35W.
