Non-operational -40°C to 70°C
Humidity
90% relative humidity
(c)
Envir
onme
ntal
Airflow
Cable Type Host Aisle - HSK to Port Cold Aisle @ 35C - Port to
HSK
Active
Mode@55C
STBY
Mode@45
C
Active Mode STBY Mode
Passive Cable 500LFM 100LFM 200LFM 100LFM
Active 4.55W
Cable
700LFM@50C 300LFM 200LFM 100LFM
Regul
atory
Safety CB / cTUVus / CE
EMC CE / FCC / VCCI / ICES / RCM
RoHS RoHS compliant
a.ConnectX-6 adapters supplement the IBTA auto-negotiation specification to get better bit error rates
and longer cable reaches. This supplemental feature only initiates when connected to another
Mellanox InfiniBand product.
b. Typical power for ATIS traffic load.
c. For both operational and non-operational states.
Board Mechanical Drawing and Dimensions
ConnectX-6 for OCP 3.0 Mechanical Drawing and Dimensions
For the 3D Model of the card, please refer to 3D Models at http://www.mellanox.com/page/
3d_models.
All dimensions are in millimeters. The PCB mechanical tolerance is +/- 0.13mm.
