Quadro Sync DU-06574-001_v01 | 23
MONITORING DISPLAY SYNCHRONIZATION
When working with synchronized displays it can often be difficult to verify that all the
displays are correctly synchronized. Quadro Sync provides both board and driver level
indicators for the synchronization status.
BOARD LEVEL STATUS INDICATIOR
The bracket of the Quadro Sync boards has multiple lights to provide configuration and
status information
At system startup all LED’s will turn and stay on until the graphics driver loads. Once
the driver loads, the LEDs will start to show the status of the board and GPUs.
If the LEDs do not turn on at startup, verify that the external power is correctly
connected and providing power.
