SYNC TIMING LIMITS
The Quadro Sync board has the ability to align displays and sync sources up to ±20 ppm
difference in the display timings. If the timings are outside this range the board will not
be able to synchronize them. The Frame Lock status LEDs on the board will indicate that
the board is approaching these limits as well.
Table 1. Sync Timing Limits
Display Refresh Rate (Hz) Minimum (Hz) Maximum (Hz)
200 199.996 200.004
120 119.9976 120.0024
100 99.998 100.002
60 59.9988 60.0012
50 49.999 50.001
