Monitoring Display Synchronization
Quadro Sync DU-06574-001_v01 | 25
Figure 7. Frame Lock and Stereo Sync Status LEDs
SYNC LED Status
STEREO LED Status
GPU Not connected
Stereo not active/no GPU
GPU present but not
synchronized
Stereo locked
GPU synchronized
Stereo in process of locking
GPU is synchronized but within
5% of the threshold of losing sync
GPU is synchronizing
GPU 3
GPU 2
GPU 1
GPU 0
STEREO
SYNC
0123
GPU #
