LPC2468 IRD Kit 1.2 Quick Start Guide, rev. 1.0 Page 4 of 8

3. Connect the external Condor 5VDC power supply to JPWR (2.5mm plug)

VREFJVDISP JP19JP18 JP2

Before moving to Step 3, make sure that ALL the

instructions described in Step 1 , Hardware

connections and Step 2 Jumper configuration

have been properly followed. Failure to follow

these instructions may cause the platform not to

function properly
