Physical Specifications & Clearances
13
Physical Specifications and Clearances
Water Side Pipe Connections 1-1/4” FPT
Condensate Pipe Connection 3/4” CTS Stub
Main Power Conduit Connection 1-1/2” Female Thread
120v Power Conduit Connection 3/4” Female Thread
Net Weight (Dry, no Fans) 2,300 Pounds
Net Weight (Shipping) 2,400 Pounds
Net Weight (Filled, w/Fans) 2,604 Pounds
Fan Unit Net Weight (Each) 140 Pounds
Refrigerant Charge 60.0 Pounds
Refrigerant Oil Charge 158.4 Ounces
Internal Water Volume 2.9 Gallons
Table 3: Physical Specifications
