Installation: Power Wiring
35
Power Wire Installation:
The e-Series heat pump has an incoming power feed conduit from the interior
electrical enclosure to a termination point on the top of the unit. This conduit
ships with a termination plug that will need to be removed to access the conduit.
Main and 120v power feeds will run through the same conduit. A second, smaller
conduit is used for control wires. See the Control Wiring section of this manual for
those details.
To install the power wires:
1. Identify the power access conduit in the top of the heat pump (larger of
the two electrical access points). Remove the shipping plug to access the
conduit.
2. Open the electrical enclosure box
3. Run your incoming power conduit(s) to the heat pump termination fitting.
Leave sucient exposed wire to fish into the heat pump conduit. Be sure
the wire is sized for the load and is at least as large as specified in Table 5,
or as dictated by local codes and conditions, whichever is larger.
4. Fish the incoming power wires through the conduit until they enter the
enclosure box with enough excess length to reach the appropriate
terminals. This conduit includes a midpoint access to facilitate wiring
installation.
5. Finish exterior conduit connection to the unit using a weathertight
connection method. Conduits terminate in female thread. See Table 5.
6. Connect power wires to their terminals. Use the torque specifications
in Table 5. All power distribution terminals are located in the upper right
corner of the electrical enclosure.
7. Close the electrical enclosure box.
