1) Diagnostics
2) DTC Lookup
3) System Setup
4) Tool Information
If the scan tool failstocommunicate with the vehicle,s ECU
(EngineControl Unit), a LINKING ERROR! message
shows upon the display.
Verify that the ignition is ON;
Check if the scan tool
,
s OBD II connector is securely
connected to the vehiclc
,
sDLC;
Verify that the vehicle is OBD2 compliant;
Turn the ignition off and wait for about 10 seconds. Turn the
ignition back to on and repeat the procedure from step 5.
If the LINKING ERROR message does not go away, then
there might be problems f or t h e sc an tool to communicate
with the vehicle. Contact your local distributor or the
manufacturer
,
scustomer service department for assistance.
6) Press the button to confirm. A sequence of messages displaying
the protocols will be observed on the display until the
vehicle protocol is detected.
Y
OBD2
7) After the result of State Emission Test is displayed (MIL status,
DTC counts, Monitor status), press any key for the
to come up.
Diagnostic
Menu
State Emis. Test
MIL Status
Codes Found
Monitors N/A
Monitors OK
Monitors INC
OFF
1
4
3
3
8) Use the scroll buttons to select from the
menu and press the button.
UP/DOWN Read Codes
Y
9) Use the scroll buttons to select or
from the menu and press the
button.
UP/DOWN Stored Codes
Pending Codes Trouble Codes Y
Diagnostic Menu
1) Read Codes
2) Erase Codes
3) Datastream
4) Freeze Frame
5) I/M Readiness
6) O2 Monitor Tesst
Trouble Codes
1) Stored Codes
2) Pending Codes
Generic
Engine Coolant Temperature
Sensor 1 Circuit
P0115
$11
pd
1/1
If there are noDiagnostic T rouble Codes present, the display
will indicate No Codes Are Stored in the Module!
10) View DTCs and their definitions on screen.
To Next Page
