O2 Mon. B1S1
Rich-Lean Threshd(V)
MEAS :
MIN :
MAX :
STAT :
0.450
0.312
0.630
OK
For CAN-equipped vehicles, the test results displayed can be as
below:
3) Press the button to return to the previous menus.N
4.8 Component Test
The Component Test function allows initiating a leak test for the
vehicle
,
s EV AP system. The Scan Tool itself does not perform the
leak test, but commands the vehicle
,
s on-board computer to start
the test. Different vehicle manufacturers might have different
criteria and methods for stopping the test once it has been started.
Before starting the Component Test, refer to the vehicle service
manual for instructions to stop the test.
1) Use the scroll buttons to select from
the and press the button.
UP/DOWN Component Test
Diagnostic Menu Y
Diagnostic Menu
07) On-Board Mon. Test
08) Component Test
09) Vehicle Infor.
10) Modules Present
11) Unit of Measure
Component Test
Reading PID.01
- Please Wait -
Component Test
Evap Leak Test
Component Test
Command Sent!
Pressanykeytocon.
2) Wait a few seconds while the Scan Tool validates the PID MAP.
3) From the use the scroll
buttons to select the test to be initiated.
Component Test Menu, UP/DOWN
4) If the test has been initiated by the vehicle, a confirmation
message will be displayed on the screen.
