Erase Codes
Erase Done!
Pressanykeytocon.
Erase Codes
Erase Failure!
TurnKeyonwith
Engine Off!
Diagnostic Menu
1) Read Codes
2) Erase Codes
3) Datastream
4) Freeze Frame
5) I/M Readiness
6) O2 Monitor Test
Live Data
Reading PID.01
- Please Wait -
If you do not want to proceed with erasing the codes, press the
button to exit. A message of will
show up. Press any key to return to
If you do wish to proceed to erase the codes, then use the
scroll buttons to select . Press the button to
confirm.
Y/N Command Cancelled
Diagnostic Menu.
UP/DOWN YES Y
3) If the codes are cleared successfully, an
confirmation message will show on the display. Press any button
to return to the
Erase Done!
Diagnostic Menu.
4) If the codes are not cleared, then a message
will appear.
Erase Failure! Turn
Key on with Engine off!
5) Press any button to return to the Diagnostic Menu.
4.3 Datastream
The Datastream function allows viewing of live or real time PID
data of the vehicle,s computer modules.
datastream, UP/DOWN
Datastream Diagnostic Menu Y
1) To view use the scroll buttons to select
from the and press the button.
2) Wait a few seconds while the Scan Tool validates the PID MAP.
UP/DOWN
Complete Data Set View Data Y
3) To view entire data set, use the scroll buttons to select
from the Menu and press the
button.
