l/swig Tfte Programmer
The Programmer Section of the
Xpandor is
used to select and store patches The Program
mor display
aiso
provides information
about
the
status
of
the
machine.
SELECTING
SINGLE OR
MULTI PATCH MODE
The
Single Patch and Multi Patch
buttons select Single
or
Mufti
Patch
mode, and recall all
the
settings from the last
time
you
were in the mode. The left character of the display shows
an
"S
for Single Patch or an "M" for Multi Patch.
SELECTING PATCHES
EDITING
PATCHES
Whether in Single or Multi Patch
mode,
a
new patch can be recalled
by
pressing
two digits
or
the
-
or
-
keys
on
the Programmer
Keypad After one digit is entered, the display
shows the digit and
a
star, and waits for the
second
digit. If
a second digit »s not entered
withm
several seconds,
the
Xpander reverts
back to the original patch number.
Notice
the
underlined patch number.
The patch number
and name
will
appear in the
display,
as
well
as
the Single Patches
assigned to each voice. In Single Patch
mode
all
voices have the same patch. In Multi Patch
mode however,
each voice
can have
a
different Single Patch
The Expander is always in
edit mode. Select
pages
and change functions
as you
like. A
dot
to the
right of
the patch number appears if
a patch is edited.
Comparing the
Edited and Unedited Patch
You
can compare
your
edited
patch
with its stored version
by
pressing
the
appropriate patch
mode button (SINGLE if
you
are
editing
a
Single Patch, MULTI
if
you
are editing
a
Multi
Patch -realize
that
pressing
MULTI
while
in Single Patch mode
will
switch to Multi Patch
mode). When
comparing
the stored patch, the
patch
number will flash. You can switch back
and
forth
between
the edited version
and the stored version
by
pressing the appropriate
patch mode
button again
STORING PATCHES
To store
a patch,
hold
the
STORE
button. Notice that the patch number now shows
two
stars. Enter
the destination
for
your new patch on the keypad, by keying two digits while
holding
the
SI ORE
button.
SELECTING AND
EDITING
SINGLE PATCHES
WHILE
IN MULTI
PATCH
MODE
The six PATCH EDIT
buttons are
used to access the individual voices and their patches.
When
you
press one of these PATCH EDIT
buttons
in Multi mode,
the
underline
will
move
to
the voice whose patch
is being
displayed.
While holding the PATCH EDI X button, the name
of
the Single
Patch on
that voice is displayed.
Selecting an
individual voice causes the
Xpander
to
enter Single Patch mode
for
that voice.
Use the keypad to select a
new Single Patch for that voice,
or
use
any
of the same Single
Patch functions to edit, compare or
store that
Single
Patch Pressing an already
underlined
patch edit button
will compare the edited patch with the one
in memory Holding STORE
and
selecting the destination patch
number on the Keypad
will store the patch.
You can switch among of the six voices' Single
Patches with the PATCH
EDIT
buttons.
The
underline in the display shows your
current
location, and the dot to
the
right
of each
patch
number indicates
if
that
patch
has
been
edited.
