Blower RPM (select equipment models, only):
Actual RPM feedback from indoor blower motor.
Lockout Timer:
If a lockout timer is active, this will show the current time val-
ue. See equipment manual for details on lockout timers.
Seconds
Single-Stage and Two-Stage
Heat Pump/AC Status
Stage: (Heat/Cool):
Displays stage of heating or cooling that the Heat Pump/AC
is delivering.
OFF, HIGH, LOW
Defrost:
NO, YES
Outdoor Coil Temp:
Temperature of the outdoor unit coil (only available on
2-stage communicating outdoor units).
ºF or ºC (default = ºF)
Multistage (greater than 2)
Heat Pump/AC Status
Stage: (Heat/Cool):
Displays stage of heating or cooling that the Heat Pump/AC
is delivering.
OFF, 1, 2, 3, 4, 5, DEFROST
Outdoor Coil Temp:
Temperature of the outdoor unit coil.
Compressor RPM
Speed of the compressor.
Suction Pressure (see image above)
Pressure in the suction line.
