Ocean Optics QE Pro - Shipment Components

1: Introduction
891-00000-000-02-201603 5
Computer
Interface
Operating System Requirements
Part Needed
Description of Part
Computer via
USB Port
OceanView: Windows XP/7/8 or Vista (32-
bit only) for PC, OS X version 10.5 Intel or
later for Mac, or any version released for
an x86 or amd64 platform since 2010 for
Linux
USB-CBL-1
(included)
Cable that connects from USB
port on QE Pro to USB port on
desktop or notebook PC
Desktop or
Notebook PC
via Serial Port
Any 32-bit or 64-bit Windows operating
system
HR4-
BREAKOUT
(not
included)
Adapter block that enables
connection from serial port on
QE Pro to serial port on
desktop or notebook PC;
comes with 5 VDC power
supply (required when
connecting to serial port)
Shipment Components
 QE Pro Spectrometer
 USB-CBL-1
 + 5VDC power supply
The following information and documentation also ships with the QE Pro Spectrometer:
 Packing List
The packing list is inside a plastic bag attached to the outside of the shipment box (the invoice
arrives separately). It lists all items in the order, including customized components in the
spectrometer (such as the grating, detector collection lens, and slit). The packing list also includes
the shipping and billing addresses, as well as any items on back order.
 Wavelength Calibration Data Sheet
Each spectrometer is shipped with a Wavelength Calibration Data Sheet that contains information
unique to your spectrometer. Your spectrometer operating software reads this calibration data
from your spectrometer when it interfaces to a computer via the USB port.
Note
Please save the Wavelength Calibration Data Sheet for future reference.
