Ocean Optics QE Pro - Spectrometer and Detector Specifications

B: Specifications
891-00000-000-02-201603 29
QE Pro Specifications
The following sections provide specification information for the CCD detector in the QE Pro, as well as
the QE Pro Spectrometer itself.
CCD Detector Specifications
Specification
Value
Detector
Hamamatsu S7031-1006 Low Etaloning
Detector range
185-1100 nm
Pixels
1024 active
Pixel size
24 μm
2
Quantum efficiency
90% peak; 65% at 250 nm. See Quantum Efficiency of Detector graph
below.
QE Pro Spectrometer Specifications
Specification
Value
Integration time
8 ms to 60 minutes
Typical dynamic range
~85,000:1
Signal-to-noise ratio
1000:1 (single acquisition)
Readout Noise
2.5 counts RMS (typical)
Linearity
Corrected
0.5% nonlinearity (max)
f number
f/4
Activation time of optional internal
shutter
11 ms
Trigger jitter
10 ns
Fiber optic connector
SMA 905 and Ocean Optics FC
Gratings
14 gratings available (H1--H14), HC1 grating
