USB2000 Specifications
USB2000 Operating Instructions 5
2 USB2000 Specifications
This chapter contains information on spectrometer operation, specifications, and system compatibility. It also
includes accessory connector pinout diagrams and pin-specific information.
How the USB2000 Works
The following diagram illustrates the movement of light through the optical bench of the USB2000 Spectrometer.
You can customize the items marked with an asterisk (*) when ordering the USB2000.
Note: The optical bench has no moving parts that can wear or break. Ocean Optics secures all components in
place permanently at the time of manufacture.
Figure 2-1: USB2000 Spectrometer with Components
The USB Component Table on the following page explains the function of each numbered component in the
USB2000 Spectrometer diagram (Figure 2-1).
