Troubleshooting
USB2000 Operating Instructions 17
Troubleshooting the Serial Port Configuration
Occasionally, you may encounter problems with the serial port connection and/or software. Perform the following
steps to troubleshoot the serial port connection:
1. Cycle the power on the USB2000 and restart the OOIBase32 software. This ensures that the software
and the USB2000 are synchronized.
2. Determine the serial port (COM port) number:
Operating System Instructions
Windows 95/98/ME
1. Right-click on My Computer
2. Select Properties
3. Click on the Device Manager tab
Windows 2000/XP
1. Select Start | Settings | Control Panel | System
2. Select the Hardware tab
3. Click the Device Manager button.
Windows NT
1. Select Start | Programs | Administrative Tools (common) NT
Diagnostics
3. Double-click on the Ports (COM & LPT) option to display COM port numbers. Ensure that no warning icon
appears next to the USB2000’s COM port.
4. Verify that the COM port to which the USB2000 is interfaced is active. If the ports on the PC are not
labeled and you do not know the COM port number, use trial-and-error to find the correct COM port.
Open OOIBase32 and view the displayed graph. If the correct COM port is selected, you will see a
dynamic trace responding to light near the bottom of the graph. If the correct COM port is not selected,
you will see a straight line at zero counts.
5. Disable virus protection to ensure timely and complete data transfer (optional – some computers require
this step).
Older Version of OOIBase32 Installed
If the PC you want to use to interface to your USB2000 already has an older version of OOIBase32, you need to
install the latest version of OOIBase32. You can download the latest version of OOIBase32 from the Software and
Technical Resources CD or from the Ocean Optics web site at the following URL:
http://
www.oceanoptics.com/technical/softwaredownloads.asp.
You do not need to uninstall previous versions of OOIBase32 when upgrading to the latest version.
