17 Technical Data
Instruction Manual BIOM® 5 (G/55400/0413/en) 39 / 40
Dimensions BIOM
®
5ml and BIOM
®
5cl
Weight
Operating Conditions for Optical System
Sterilization and Disinfection Procedures
Dimensions (W x D x H) 63 x 112 x 124-160 mm
(2.5 x 4.4 x 4.9-6.2 in)
Overall height approx. 137-173 mm
(5.4 - 6.8 in)
Travel of the safety rod
approx. 29 mm (1.14 in)
BIOM® 5m approx. 186 g (0.41 lbs)
BIOM® 5ml approx. 190 g (0.42 lbs)
BIOM® 5c approx. 250 g (0.56 lbs)
BIOM® 5cl approx. 260 g (0.57 lbs)
Reduction lens approx. 30 g (0.07 lbs)
Front lens: depending on the model approx. 3—10 g
(0.007 —0.02 lbs)
Temperature +10°C to +40°C
Humidity 30% to 70%
Air pressure 700 hPa to 1060 hPa
BIOM® 5
Steam auto-
clave, 134°C
Reduction lens (only the reduction lenses listed in
this manual)
Steam auto-
clave, 134°C
Ophthalmoscopy lens (only the lenses listed in this manual) Steam auto-
clave, 134°C
Adapter Steam auto-
clave, 134°C
Drive belt Steam auto-
clave, 134°C
