OCULUS BIOM 5c - 16.2 Sterilization Components for the BIOM 5; 16.3 Stereoscopic Diagonal Inverter Systems for the BIOM 5; 17 Technical Data

17 Technical Data
38 / 40 Instruction Manual BIOM® 5 (G/55400/0413/en)
16.2 Sterilization Components for the
BIOM
®
5
16.3 Stereoscopic Diagonal Inverter
Systems for the BIOM® 5
17 Technical Data
Dimensions BIOM
®
5m and BIOM
®
5c
Component Order no.
Sterilization container with tray for the BIOM® 5 and its
accessories
55180
Insert for sterlization container
55185
Paper filters for sterilization container (100 pcs/box)
55190
Component Order no.
SDI® 4c (6-15 V) 54320
SDI® 4e (6-15 V) 54300
SDI® 4m (mechanical) 54302
Types for Leica microscopes:
SDI® 4c (6-15 V) 54330
SDI® 4e (6-15 V) 54310
SDI® 4m (mechanical) 54312
Width 63 x 112 x 110-145 mm
(2.5 x 4.4 x 4.3-5.7 in)
Overall height approx. 123-158 mm
(4.8-6.2 in)
Travel of the safety rod approx. 29 mm (1.14 in)
