Oki B410D User Manual

Paper recommendations > 33
> Envelopes should be loaded flap down, face up with the top edge to the left and
short edge into the printer.
> Load Transparencies face up and top edge into the printer.
> For heavyweight paper or cardstock open the rear output cover to collect the
printed output. This will give the paper a nearly straight path through the
machine, avoiding paper jams and damage to the paper.
3. B420, B430: If required, set the media size and orientation in the media menu
using the control panel, then issue the print command.
B410: If required, set the media size and orientation in the Printer Menu Setup tool,
then issue the print command.
P APER FEED , SIZE AND MEDIA SETTING
The process used to fuse (fix) the printed image to the paper involves a mixture of pressure
and heat. Too much heat will cause lightweight paper to crease or curl and corrugations in
transparencies. Too little heat will cause the image not to fuse fully into heavyweight paper.
B410 D AND B410 DN
You can change the media type as follows:
1. Start the Printer Menu Setup tool.
2. Click Media Menu.
3. Click on the paper tray being used. Adjust the media type to the required setting
and, if necessary, the paper size to the size of the paper being used.
4. Click on the Setup tab and click Apply the changed settings, then OK to set the
printer to the new media type.
NOTE
Do not select Duplex printing on envelopes.
CAUTION!
Damage to the printer may occur if the incorrect paper setting is
used when printing on a different media.
NOTE
> You can also set the media type in your printer driver. However, the
printer driver settings will override the settings on the control panel or
Printer Menu Setup Tool.
> Remember to reset the printer for normal paper after printing on a
different media.
NOTE
Although media properties can be set in the printer driver for particular jobs,
when filling a tray with media it is recommended that you manually set the
printer to match the media as described here.

Oki B410D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Processor model	PowerPC405
Maximum internal memory	288 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	1 sheets
Envelopes sizes	C5, C6, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 120gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Power requirements	230 VAC, 50-60 Hz
Compatible operating systems	Windows 2000 / XP / XP x64 / Server 2003 / Server 2003 x64 / Vista (32-bit) / Vista (64-bit) / UNIX / Linux; Mac OS X PowerPC 10.2.8 + / OS X Intel 10.4.4 +
Display	LCD
Maximum duty cycle	50000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	268 x 369 x 395 mm
