Oki B410D User Manual

Consumables and maintenance > 67
G ENERATING A CLEANING PAGE
If the printed page shows signs of fading, streaking or erratic marks, the problem may be
cleared by generating a drum cleaning page as follows.
B410 D AND B410 DN
Using the Printer Menu Setup Tool
1. Start the Printer Menu Setup Tool for the printer.
2. Click Maintenance Menu.
3. Select Cleaning Page Print and click Execute.
4. Open the Manual Feed Tray and insert a sheet of Letter/A4 plain paper between the
paper guides, then click OK.
5. The printer grips the paper and prints a cleaning page.
6. If subsequent printing appears faded or uneven, try replacing the toner cartridge.
Using the Online button
1. Press the Online button to take the printer OFF LINE.
2. Open the Manual Feed Tray and insert a sheet of Letter/A4 plain paper between the
paper guides, for loading paper See “Multi purpose tray and manual feed tray” on
page 32.
3. Press and hold down the Online button for at least seven seconds.
4. The printer grips the paper and prints a cleaning page.
5. Return the printer ONLINE by pressing the Online button.
6. If subsequent printing appears faded or uneven, try replacing the toner cartridge.
B420 DN , B430 DN
1. Pull down the Multi Purpose Tray (1), fold out the paper supports (2), and adjust the
paper guides to the width of the paper (4).
2. Insert a sheet of Letter/A4 plain paper between the paper guides and push the
colored set button to engage the tray (3).
3. Press the Menu or button repeatedly until MAINTENANCE MENU is displayed,
then press the button.
4. Press the or button until CLEANING PRINT is displayed.
1
3
4
2

Oki B410D Specifications

General

Color	No
Duplex printing	Yes
Print technology	Laser
Maximum resolution	2400 x 600 DPI
Time to first page (black, normal)	5.5 s
Print speed (black, normal quality, A4/US Letter)	28 ppm
Internal memory	32 MB
Processor model	PowerPC405
Maximum internal memory	288 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	53 dB
Total input capacity	250 sheets
Total output capacity	150 sheets
Multi-Purpose tray input capacity	1 sheets
Envelopes sizes	C5, C6, DL
Maximum print size	210 x 297 mm
Media weight (tray 1)	60 - 120gsm
Paper tray media types	Envelopes
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5
JIS B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Multi-Purpose Tray media weight	60 - 163 g/m²
Power requirements	230 VAC, 50-60 Hz
Compatible operating systems	Windows 2000 / XP / XP x64 / Server 2003 / Server 2003 x64 / Vista (32-bit) / Vista (64-bit) / UNIX / Linux; Mac OS X PowerPC 10.2.8 + / OS X Intel 10.4.4 +
Display	LCD
Maximum duty cycle	50000 pages per month

Weight and Dimensions

Dimensions (WxDxH)	268 x 369 x 395 mm
