Operation > 44
2. You can print watermark text behind the main page image. This is useful for marking
documents as draft, confidential, etc.
If you would like to print on special stationery, such as forms and letterhead, but do
not want to use pre-printed stationery, you can create your own using Overlays (for
B430dn). For more information on Overlays and Macros, refer to “Overlays and
Macros (Windows only)” on page 55. The Overlays button also offers guidelines on
how to carry out manual duplex printing.
3. You can select up to 999 copies to print consecutively, although you will need to top
up the paper tray during such a long print run.
4. Your printed pages can be scaled to fit larger or smaller stationery.
5. Using the Advanced button gives you access to the facility to set mirror image
printing and negative image printing.
6. A single on-screen button restores the default settings.
S
ETTING
FROM
W
INDOWS
CONTROL
PANEL
When you open the driver properties window directly from Windows, rather than from
within an application program, a somewhat more extensive range of settings is provided.
Changes made here will generally affect all documents you print from Windows
applications, and will be remembered from one Windows session to the next.
PCL emulation
The main tabs are the General Tab, Advanced Tab and Device Options Tab.
General tab
1. This area lists some of the main features of your printer, including optional items.
2. This button opens the same windows as described earlier for items which can be set
from within application programs. Changes you make here, however, will become
the new default settings for all Windows applications.
3. This button prints a test page to ensure that your printer is working.
NOTE
The above features are provided by the Windows XP operating system and will
vary with other operating systems.
1
2
3
My Printer Properties

Table of Contents

Other manuals for Oki B410D

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Oki B410D and is the answer not in the manual?

Oki B410D Specifications

General IconGeneral
ColorNo
Duplex printingYes
Print technologyLaser
Maximum resolution2400 x 600 DPI
Time to first page (black, normal)5.5 s
Print speed (black, normal quality, A4/US Letter)28 ppm
Internal memory32 MB
Processor modelPowerPC405
Maximum internal memory288 MB
Sound power level (standby)30 dB
Sound pressure level (printing)53 dB
Total input capacity250 sheets
Total output capacity150 sheets
Multi-Purpose tray input capacity1 sheets
Envelopes sizesC5, C6, DL
Maximum print size210 x 297 mm
Media weight (tray 1)60 - 120gsm
Paper tray media typesEnvelopes
Non-ISO print media sizesExecutive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)A4, A5
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
Multi-Purpose Tray media weight60 - 163 g/m²
Power requirements230 VAC, 50-60 Hz
Compatible operating systemsWindows 2000 / XP / XP x64 / Server 2003 / Server 2003 x64 / Vista (32-bit) / Vista (64-bit) / UNIX / Linux; Mac OS X PowerPC 10.2.8 + / OS X Intel 10.4.4 +
DisplayLCD
Maximum duty cycle50000 pages per month
Weight and Dimensions IconWeight and Dimensions
Dimensions (WxDxH)268 x 369 x 395 mm
