B6250/B6500 User’s Guide> 48
Cleaning Procedure
The following procedure explains how to clean the feed roll set in the
paper tray. Follow this procedure also when cleaning the feed rolls
inside of the printer and the tray module.
NOTE
> The feed roll is a regular replacement part.
1. Pull the paper tray out of the printer.
2. While pushing the retard part (see
right diagram) down (1), widen the
tab on the feed roll to loosen it (2)
and then slowly remove the feed
roll from the shaft of the paper
tray (3).
3. Wipe the rubber parts with a wet
but well-wrung soft cloth.
4. Turn the short tab of the feed roll
to the right and slowly push it onto
the shaft of the paper tray.
To Next Page
