Oki B710dn User Manual

10 / English
Connect the power cord
When connecting the power cord, take heed of the
information given in “Safety precautions” on page 4.
1. Ensure that the printer power switch is in the OFF
<{> position.
2. Connect the power cord to the power cord
connector at the back of the printer. Connect the
other end of the power cord to the power outlet.
3. Press the power switch of the printer to the ON
<> position.
The power will be applied and the control panel will
display that the printer is “Ready to Print”.
Windows Installation
Print a MenuMap
1. Press the <Menu> button then < > until
[Information Menu] is highlighted and press
<Enter>.
2. Press the <Menu> button then < > until
[Information Menu] is highlighted and press
<Enter>.
3. Scroll down < > to and highlight [Print Menu
Map] and press <Enter> to select the highlighted
menu item.
4. Press <Enter> again to execute.
A summary of the “MenuMap” prints. This shows the
current configuration for each Menu item, including the
network setting.
Print the Configuration
Sheets
1. Connect the Printer to your network via the
network connection (illustrated in “Connect an
Interface Cable” on page 9).
2. Turn on the Printer and wait for approximately one
minute for the Network DHCP server to allocate an
IP address to the Printer.
3. If your Network does not have DHCP running then
it must be configured manually.
4. You can test your network connection by entering
the Printer’s IP address into the browser’s Address
window (see “Set the Printer Configurations via a
Web Page” on page 11).
Installing the Printer on a
Network
Install the Driver
1. Insert the CD in the CD-ROM drive. The CD will
autorun.
If it doesn’t, click Start > Run > Browse. Browse to
your CD-ROM drive, double-click Install.exe. Click
OK.
2. Select your language.
3. Accept the License Agreement.
The Installer screen appears.
4. Click Install Driver.
5. Select network printer.
6. Follow the on-screen instructions.
7. When prompted, select printer emulation (PS or
PCL).
NOTES
> If “Found New Hardware” displays on your
screen, click Cancel.
> Depending on the network environment
used, it may take about one minute before
the printer is ready for printing.
NOTE
> The layout of the [Functions] menu
structure may differ depending on the
(options) configuration and settings of the
printer.

Oki B710dn Specifications

General

Wi-Fi	No
Network ready	Yes
Print technology	-
Maximum resolution	1200 x 1200 DPI
Time to first page (black, normal)	8 s
Print speed (black, normal quality, A4/US Letter)	40 ppm
Printer fonts	Barcode, PCL, PostScript
Maximum duty cycle	200000 pages per month
Recommended duty cycle	5000 pages per month
Page description languages	PCL 5e, PCL 6, SIDM
Flash memory	40 MB
Maximum internal memory	625 MB
Sound power level (standby)	30 dB
Sound pressure level (printing)	64 dB
Display	LCD
Total input capacity	150 sheets
Total output capacity	500 sheets
Maximum input capacity	1800 sheets
Paper tray 2 input capacity	550 sheets
Envelopes sizes	C5, DL
Maximum print size	216 x 297 mm
Media weight (tray 1)	64 - 216gsm
Paper tray media types	Plain paper
Non-ISO print media sizes	Executive (184 x 267mm), Legal (media size), Letter (media size), Statement (140 x 216mm)
ISO A-series sizes (A0...A9)	A4, A5, A6
ISO B-series sizes (B0...B9)	B5
Maximum ISO A-series paper size	A4
Standard interfaces	Ethernet, Serial, USB 2.0
Power consumption (standby)	169 W
Power consumption (printing)	904 W
Sustainability certificates	ENERGY STAR
Storage temperature (T-T)	0 - 35 °C
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	15 - 85 %
Power supply type	AC
Custom media sizes	76/215 - 127/1219 mm
Power requirements	AC 230V, 50/60Hz
Networking features	10/100 Base-TX
Authentication method	EAP-MD5, PEAP, EAP-TLS
Compatible operating systems	Microsoft Windows 2000/XP Home/XP Professional/Vista/7/Server 2003/Server 2008, Mac OS X 10.2 - 10.6
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.1x
Non-operating relative humidity (non-condensing)	15 - 80 %
Bundled software	Template Manager, PrintSuperVision, OKI LPR, PDF Print Direct, Font & Macro Manager, Status Monitor

Weight and Dimensions

Dimensions (WxDxH)	422 x 572 x 404 mm
