Oki C 3200n Service Manual

Oki Data CONFIDENTIAL
42615101TH Rev.8 195 /
Error No.
370
371
372
373
380
381
382
383
390
391
392
400
Name
Duplex reversal
Duplex input
Feed error at Duplex
Multi-feed in Duplex Unit
Feed
Transport
Exit
Duplex entry
Feed error at front feeder
Tray1
Tray2
Paper size error
Jam release method
Jam release method 3
Jam release method 3
Jam release method 1
Jam release method 3
Jam release method 1
Jam release method 2
Jam release method 2
Jam release method 2
Jam release method 1
Jam release method 1, 4
Jam release method 4
Jam release method 1
Reference
J1
J2
J3
J4
J5
J6
J7
J8
J9
J10
J11
J12
Corresponding sensor
DUP-IN, DUP-R
DUP-F, DUP-R
IN1
DUP-B
IN2, WR
IN1, IN2, WR, EXIT
EXIT
EXIT, DUP-IN, DUP-R
IN2, WR
IN1
2nd-IN
IN1
(3) Error number and jam location at paper jam
Diagram of jam location
J7(382:EXIT)
J8(383:DUPLEX ENTRY)
J1(370:DUPLEX REVERSAL)
DUP-IN SENSOR
DUP-B SENSOR
2nd-IN SENSOR
IN1 SENSOR
IN2 SENSOR
WR SENSOR
DUP-R SENSOR
DUP-F SENSOR
EXIT SENSOR
J4(373:MULTIFEED IN DUPLEX UNIT)
J2(371:DUPLEX INPUT)
J11(392:TRAY2)
J10(391:TRAY1)
J3(372:MISS FEED AT DUPLEX)
J9(390:MISS FEED AT FRONTFEEDER)
J6(381:TRANSPORT)
J5(380:FEED)
J12(400:PAPER SIZE ERROR)
