Installing upgrades > 69
SD
CARD
The optional SD card enables collating of printed pages and can be used to store overlays
and macros, fonts, and secure or proof documents waiting to be printed.
1. Switch the printer off and disconnect the AC power cable.
2. Press the cover release and open the printer’s output tray fully.
3. Pull down the MP Tray using the depressions. Lift the front cover release lever and
lower the front cover.
4. Loosen the screw (a) securing the right-hand side cover. Lift the edge of the side
cover slightly and pull the cover away from the printer at the top. Lift the cover
slightly to detach it from the printer. Place it safely to one side.
WARNING!
If the printer has been powered on recently, the fuser will be hot.
This area is clearly labelled. Do not touch.
a
