4. REPLACEMENT OF PARTS
Shaft-lift-up
(1) (2)
(3) (4)
(1) Apply a moderate amount (Class C) of Molykote
(EM-30L) to the inner wall of the hole (the hatched area).
(2) Insert the shaft-lift-up from the plate-side-R side.
(3) Apply a moderate amount (Class C) of Molykote (EM-30L)
to the shaft on each end of it (the hatched area)
(4) Move the shaft from side to side and rotate it to spread the
applied Molykote appropriately.
Class-C Molykote (EM-30L)
to all-around gear tooth surfaces
Class-C Molykote (EM-30L)
to all-around gear tooth surface
Shafts-lift-up
Gear-reduction-L-up
Gear-reduction-L-UP4
Plate-side-Assy.
