44015503TH Rev. 1
135 /
Oki Data CONFIDENTIAL
5. MAINTENANCE MENUS
4. With PRINT EXECUTE on the lower display after the operation in step 2, pressing
the ENTER button executes test printing by using the setting made in 4.2 steps
2 and 3. The test printing is cancelled by pressing the CANCEL button. When
detected, an alarm shown in the Detail section of the following list is displayed on
the operator panel, causing the printing to stop (refer to the operator panel display
detail shown in section 5.3.2.14, where the messages displayed are different from
those in PU test printing).
Panel Display Message Detail
PAPER END
SELECTED TRAY
No paper exists.
DUPLEX UNIT IS
NOT INSTALLED
The duplex unit is not
installed.
SELECTED
TRAY IS
NOT INSTALLED
The selected tray is not
installed.
REMOV
E PAPER
OUT OF DUPLEX
An internal error of the
duplex unit.
INST
ALL CASSETTE TRAY
OPEN
The cassette of the selected
tray is slid out.
Print patterns (cannot be used for print quality checking)
0 and 8 to 15: Prints a blank page.
Pattern 1 Pattern 2
Note! Printing 100% of solid black print
(pattern 7) contained in the local
printing functions causes an offset.
To prevent this, the colors to print
concurrently to produce No. 7 solid
print copies must be limited to two or
less by making each print color settings
as instructed in step 3.
P
attern 3 Pattern 4
Pattern 5 Pattern 6
Pattern 7
To Next Page
