- 113 -
5. Management / Setting the Printer
6
Click [Submit].
The new settings take effect when the network function of this machine restarts.
• If you were unable to set up IPSec due to the inconsistency of the parameters that were specified, you cannot access
the Web page. In such a case, disable the IPSec from the operator panel of this machine or initialize the network
settings.
Proceed to "Setting a Computer".
Setting a Computer
Set IPSec to a computer.
Follow the procedure below, and be sure to perform all the steps in order.
• Creating an IP Security Policy
1
Click [Start], and then select [Control Panel] > [System and Security] >
[Administrative Tools].
2
Double-click [Local Security Policy].
3
Click [IP Security Policies on Local Computer] in the [Local Security Policy]
window.
4
Select [Create IP Security Policy] from the [Action] menu.
5
Click [Next] in [IP Security Policy Wizard].
6
Enter [Name] and [Description], and then click [Next].
7
Clear the [Activate the default response rule (earlier versions of Windows
only)] check box, and then click [Next].
8
Select the [Edit Properties] check box, and then click [Finish].
• Setting Key Exchange
1
Select the [General] tab in the New IP Security Policy Properties window.
2
Click [Settings].
3
Enter a value (minutes) in [Authenticate and generate a new key after every] in
the [Key Exchange Settings] window.
• Specify the same value as [Lifetime] in the "Phase1 Proposal" setting in "Setting This Machine". Enter a value
in minutes in this step even if [Lifetime] is specified in seconds.
4
Click [Methods].
5
Click [Add] in the [Key Exchange Security Methods] window.
6
Specify [Integrity algorithm], [Encryption algorithm], and [Diffie-Hellman
group].
• Select the same value specified in [IKE Encryption Algorithm], [IKE Hush Algorithm], and [Diffie-Hellman
group] in the "Phase1 Proposal" setting in "Setting This Machine".
7
Click [OK].
8
Select [OK] in the [Key Exchange Security Methods] window.
9
Click [OK] in the [Key Exchange Settings] window.
• Setting an IP Filter
1
Select the [Rules] tab in the IP security policy properties window.
2
Click [Add].
3
Click [Next] in [Security Rule Wizard].
4
Select [This rule does not specify a tunnel] on the [Tunnel Endpoint] screen,
and then click [Next].
5
Select [All Network Connections] on the [Network Type] screen, and then click
[Next].
6
Click [Add] on the [IP Filter List] screen.
To Next Page
