- 121 -
5. Management / Setting the Printer
• For details on the LDAP server and encryption setting, contact your network administrator.
1
Open the Web page of this machine.
Open the Web Page of This Machine
2
Log in as the administrator.
3
Select [Admin Setup].
4
Select [Network] > [LDAP].
5
Enter the FQDN or IP address of the LDAP server in [LDAP Server].
• When you select [Digest-MD5] or [Secure Protocol] for [Method] in step 9, do not enter an IP address, but enter
an FDQN. FQDN is a combination of a host name and domain name. (Example: Server1.domain1.local)
6
Enter the port number of the LDAP server in [Port Number].
7
Specify a value of time-out to wait for the search results in [Timeout].
8
Specify a BaseDN to access the LDAP server in [Search Root].
9
Select a necessary authentication method in [Method].
[Anonymous]: Connects to the LDAP server by Anonymous authentication.
[Simple]: Connects to the LDAP server by Simple authentication.
[Digest-MD5]: Connects to the LDAP server by Digest-MD5 authentication.
[Secure Protocol]: Connects to the LDAP server by Secure Protocol (Kerberos)
authentication.
• If you select [Anonymous], the machine always authenticates by Anonymous authentication. If you use the
LDAP server for the LDAP Name authentication, select an authentication method other than [Anonymous].
• If you select [Digest-MD5], you must set the DNS server.
• If you select [Secure Protocol], you must set SNTP server, DNS server, and secure protocol server.
10
If you select other than [Anonymous] in step 9, specify the user ID and
password to log in to the LDAP server.
11
Select the encryption method in [Encryption].
[None]: Encryption is not performed.
[LDAPS]: Encryption in LDAPS method is performed.
[STARTTLS]: Encryption in StartTLS method is performed.
12
Click [Submit].
Setting the LDAP Server
