When a Paper Jam Occurs
- 6 -
4
If the Multi-Purpose Tray (MPT) is closed,
hold both sides of the Multi-Purpose Tray
(MPT), and position it in front of you.
5
Lift the paper set cover and take it out.
6
Insert your finger into the recess on the
right side of the machine and pull the front
cover open lever to open the front cover
forward.
7
Remove the jammed paper gently by pulling
the edge of paper if the edge of jammed
paper can be seen. If you cannot find the
edge of jammed paper, go to step 8.
8
Remove the paper from the back gently if
the edge of paper cannot be seen.
9
Close the front cover.
Front cover
Front cover
open lever
To Next Page
