5. MAINTENANCE MENUS
Tabl e 5 - 4
Unit name displayed Driving restriction Remarks
ID MOTOR All of the (black, yellow, magenta and cyan)
image drums must be removed.
–
BELT MOTOR All of the (black, yellow, magenta and cyan)
image drums must be removed.
–
FUSER_MOTOR – –
REGIST MOTOR – –
T1 HOPPING MOTOR – –
FRONT MOTOR – –
REGIST SHUTTER – –
DUPLEX MOTOR – –
DUPLEX CLUTCH – –
T2 HOPPING MOTOR – Option
T2 FEED CLUTCH – Option
ID UP/DOWN The top and front cover must be closed. –
LV FAN TEST – –
ID FAN TEST – –
FRONT FAN TEST – –
Note: Display while ID UP/DOWN is in progress
MOTOR & CLUTCH TEST
ID UP/DOWN ***
***
: Identifies the number of executions
Display after pressing REGIST SHUTTER [
] button
MOTOR & CLUTCH TEST
SHT ***
***
: Identifies the number of executions
