- 194 -
6. Maintenance
2
Hold the handle (B) and open the scanner unit (a) completely.
3
Press the open button (A) and open the output tray (b) until it clicks.
4
Take all the four image drums out of the machine, and then place them on a
flat surface.
5
Cover the image drums you took out with paper so that the image drums do
not expose to the light.
6
Turn the lock levers (c) on the both sides of the belt unit forward to unlock.
Possible to get burned.
The fuser unit is extremely hot. Do not touch it.
To Next Page
