ML1120 Plus/ML1190 Plus User’s Guide - Operating instructions > 52
MENU ITEM FUNCTION SETTING
Top feed menu Line Spacing Select line feed pitch. 6 LPI
8 LPI
Page Length Select the page length of
cut paper.
279.4 mm(11 )
296.3 mm(11 2/3 )
304.8 mm (12 )
355.6 mm(14 )
431.8 mm(17 )
76.2 mm(3 )
82.6 mm(3.25 )
84.7 mm(10/3 )
88.9 mm(3.5 )
93.1 mm(11/3 )
101.6 mm(4 )
127.0 mm(5 )
139.7 mm(5.5 )
152.4 mm(6 )
177.8 mm(7 )
203.2 mm(8 )
215.9 mm(8.5 )
Top feed wait
time
Select the waiting time
between setting paper
on the tray and feeding it
while the printer is waiting
for paper to be fed in cut-
paper manual feed mode.
Invalid
0.5 sec
1.0 sec
2.0 sec
Page length
control
Control the page length of
cut paper.
by MENU setting
by Actual page
length
Cut sheet auto
eject Position
Select a printable area at
the bottom of cut sheets of
paper in cut-paper mode
(the character centre
position).
6.35 mm (3/12 )
12.70 mm(6/12 )
14.82 mm (7/12 )
TOF adjust
(Cut Sheet)
Select an adjustment
value for the reference
position in regard to the
TOF position of cut-paper/
passbooks.
The position moves to the
rear of the form by [+] and
to the top of the form by [-]
in 1/144 in increments.
-20 - -1
0
+20 - +1
