ML1120 Plus/ML1190 Plus User’s Guide - Getting started > 13
2. Connect the power cable (1) to the power connector (2) on the
printer.
3. Connect the power cable to a 220/240 V AC power outlet and
switch on the outlet power.
4. Turn the printer Power Switch to ON.
5. Check that the SEL and STATUS indicators on the control panel
illuminate.
producinG a test print
To check that your printer is operational, produce a test print on a sheet
of 80 gsm A4 paper (for example) as follows:
CAUTION!
Allow at least 5 seconds between turning the printer ON after
turning it OFF. A shorter time interval between turning ON/OFF
operations may cause printer power failure.
Do not turn the printer OFF while it is printing as this may
result in damage to the print head.
1
2
