ML1120 Plus/ML1190 Plus User’s Guide - Operating instructions > 67
setting tOf pOsitiOn at tHe place Of user’s cHOice
TOF position can be set at the place of user’s choice. The reference
position refers to the first line of the paper i.e. the position to which the
printer feeds the paper when automatically loading the paper.
NOTE
Adjusting of TOF can be done in cut sheet mode or continuous
forms mode.
1. Move Paper Lever to the position of the paper to be set.
2. Continuous paper: Set the paper in Pin Tractor.
Single sheets: Do not insert the paper.
3. Continuous paper: Push the LOAD/EJECT button and the paper
will be fed to the printer
Single sheets: Set the paper in the tray and the paper will be fed
to the printer.
4. Switch to the off line.
5. Push the LOAD/EJECT button continuously and adjust the
position of printing start by combining the following buttons.
Forward (minute reline): LOAD/EJECT button + SEL button
Rear (minute reline): LOAD/EJECT button + LF/FF button
NOTE
The range set for TOF is between 2.12mm(1/12 in) and
368/4mm(14.5 in). Outside the range, the paper can not be moved.
When the paper is positioned at the required TOF, release the
buttons in Step 5 above.
To save this position as the TOF, press and hold down the LOAD/
EJECT and the LF/FF buttons together for 3 seconds under the
Select condition.
NOTE
Do not turn the Platen Knob or switch off the printer during the
above procedure.
