ML1120 Plus/ML1190 Plus User’s Guide - Operating instructions > 58
MENU ITEM FUNCTION SETTING
Symbol sets
menu
Code Page Select a code page. USA
Canada French
Multilingual
Portugal
Norway
BRASCII
Abicomp
Multilingual 858
ISO 8859-15
Rear feed
menu
Line Spacing Select line feed pitch. 6 LPI
8 LPI
Form Tear-Off Select manual or auto as
the method to advance
a continuous form to the
form tear-off position.
Manual
0.5 sec
1.0 sec
2.0 sec
Skip Over
Perforation
Select whether to skip over
perforation or not. (When a
skip over perforation setup
command is received,
the received command is
given priority.)
25.4 mm(1 )
No
Page Length Select the length of a
continuous form.
279.4 mm(11 )
296.3 mm(11 2/3 )
304.8 mm (12 )
355.6 mm(14 )
431.8 mm(17 )
76.2 mm(3 )
82.6 mm(3.25 )
84.7 mm(10/3 )
88.9 mm(3.5 )
93.1 mm(11/3 )
101.6 mm(4 )
127.0 mm(5 )
139.7 mm(5.5 )
152.4 mm(6 )
177.8 mm(7 )
203.2 mm(8 )
215.9 mm(8.5 )
Cut position
adjust
Select an adjustment value
for the position to cut the
end of a continuous form.
(In 1/180 in increments)
-30 - -1
0
+30 - +1
TOF adjust
(continuous)
Select an adjustment
value for the reference
position in regard to
the TOF position of a
continuous form.
The position moves to the
rear of the form by [+] and
to the top of the form by [-]
in 1/180 in increments.
-30 - -1
0
+30 - +1
To Next Page
