0797S20069 6-10
Adjusting the Blade Frames When Slices Vary in Thickness
WARNING
ALWAYS DISCONNECT THE SLICER FROM THE POWER SUPPLY BEFORE
ATTEMPTING ANY TYPE OF MAINTENANCE TASK.
Swing out the discharge table of the slicer. Loosen, but do not remove the two
capscrews which secure the blade frame to the swing shaft, (see below). Using an allen
wrench, loosen; but do not remove, the set screw in the fixed collar. Using a ruler, (15”
maximum), measure the distance between the blades. Gently tap the collar with a small
mallet either to the right or left until the distances between the blades is equal. When
satisfied with the location tighten the fixed collar’s set screw and tighten the two
capscrews which secure the blade frame.
