2.3.2 How to change the CRU
With the new series, thanks to the CRU design, removing the drum can be done in only
6 steps as shown below, and, because it is CRU design, no tools are required.
New colour series
No tools required!
Remove in 6 steps without having to
remove other components.
1) Open the front cover to the MFP
2) Squeeze waste toner box nozzle & eject
3) Turn lever d to the right and lower the cover
4) Whilst pressing lever ee lower the cover
5) Squeeze the yellow grip and partially eject drum unit
6
)
When
y
ellow handle becomes visible
,
com
p
letel
y
e
j
ect
